SPECIFICATIONS

AI Functions: Motion Detection

Alarm Action: FTP Photo

Alarm Type: FTP Photo

App name: Other

Audio: Two Way Audio

Audio Output: 1CH RCA

Brand Name: JOOAN

Certification: CE

Color: White,White

Color Night Vision: No

Connecting Way: 2.4ghz/5ghz Wifi Connection,Wired Connection

Connectivity: WIFI(Dual-Band)

Dimensions (L x W x D)(mm): 123*87*87mm

Feature: Motion Dection&Horizontally Auto Tracking

Features 1: Dual Lens&Dual Screen

Features 2: Outdoor WIFI Camera

High Definition: 4.0 Megapixels

High-concerned chemical: None

IP Rating: IP66

IR Distance(m): About 10M

Installation: Normal

Internal Storage: None

Lens (mm): 3.6mm

Lens Quantity: Dual Lens

Megapixels: 4MP

Minimum Illumination(Lux): 0.3 LUX

Movement Range(Pan): 0°-360°

Night Vision: Support Color Night Vision

Operating Temperature: -10°-60°

Optical Zoom: None

Origin: Mainland China

Package: Original Retail Box

Phone App: cam720

Power Consumption(W): 3W

Power Mode: Mains Electricity

Power Source: Normal

Power Supply: Normal

Power Supply(V): 5V1.5A

Rechargeable Battery: None

Scene: Indoor and outdoor

Sensor: CMOS

Sensor Brand: SmartSens

Shell Material: Plastic,Plastic

Smart home platform: None

Special Features: Waterproof / Weatherproof,Waterproof / Weatherproof

State: In Stock

Storage: SD Card&Cloud Storage

Style: Box Camera

Supported Mobile Systems: Android,iOS

Supported Operating Systems: No

TF Card: None

Technology: Pan / Tilt / Zoom

Video Compression Format: H.264

Viewing Angle : 90°

Zoom: 4X

Zoom type: Digital zoom

is_customized: No

Brand: JOOAN

Model: W3

APP: cam720

Resolution: 4K

Lens specifications: 4mm

Feature:Dual Lens&Dual Screen

Digital Zoom:Support 5X Zoom

Voice intercom: Support

Motion detection: Support

Color or Infrared night vision: Support

Use scenario: outdoor & indoor monitoring

Lens size: 1/3"

Number of infrared/white light: 10 infrared + 10 white light

Connection methods: 2.4Ghz or 5Ghz WiFi&RJ45 Ethernet cable connection

Storage methods : SD card(maximum 256G）&Cloud storage(not free)

Video format: PAL/NTSC

Video compression standard: H.264

Infrared distance: 0-10m

PTZ pan-tilt adjustment angle: horizontal direction: 355° vertical direction: 90°

Network protocol:ONVIF/RTSP/FTP/HTTP/DHCP/DDNS/NTP/UPnP

Operating temperature: -10℃～+55℃

Power supply methods: DC5V1.5A

Power interface: Type-C

Picture push: Support

Video playback: Support

Intrusion alarm: Support

APP limited add camera number:no limited

Multi-device online viewing: Support(A camera can be linked to a main account and shared with up to 5 sub accounts.)

SD Card Usage Time Reference：cctv camera sd card requires a high-speed sd card, so there will be no lag when watching the recorded video

32G can record video for 5~8 days

64G can record video for 10~16 days

128G can record video for 15~25 days

256G can record video for 20~35 days

Package includes:1 x CCTV Camera;1 x Mounting bracket;1 x USB power cable;1 x Screw bag;1 x instruction manual
