SPECIFICATIONS

Aperture: f2.0

App: Eseecloud

Brand Name: ZJGC

Customized support: OEM, ODM

Data Storage Options: Cloud,Memory Card

Function: Two-Way Audio,Pan-Tilt,Built-In Mic,Wide Angle,Full Color

IP Rating: IP65

Image Output: Main stream: 1920*2160@15fps; Sub stream: 800x896@15fps

Keyword: Security Surveillance System

Lens: 2.8-12 mm

Material: Plastic

Model Number: SQ02

Noise reduction: Support 2D/3D noise reduction

Pixels: 4 MP

Place of Origin: Guangdong, China

Power Supply: DC5V, TYPE-C interface

Product name: Wireless WiFi CCTV Camera

Sensor: CMOS,1/4.6" CMOS Sensor CMOS Sensor

Special Features: Human Motion Tracking,Night Vision,Motion Detection,Waterproof / Weatherproof

Storage: Cloud and Maximum 256GB SD Card (Not include)

Style: Pan/Tilt Camera

Type: Smart Home IP PTZ Camera

Video Compression Format: H.265

Viewing Angle: Pan: 0-320°, Tilt: 0-90°

Warranty: 1 Year

Wireless Network: Supports IEEE802.11b/g/a/n/ac/ax

Product Description

Specification

SQ02 Network Camera Specification
Operation system	Embedded Linux real-time operating system
Sensor	1/4.6” CMOS Sensor CMOS Sensor
Minimum working illumination	Color: 0.1 Lux， Black/white : 0.01 Lux
Video compression	H.264/H.265 video encoding, support dual stream
Image Output	Main stream: 1920*2160@15fps; Sub stream: 800x896@15fps
Shutter	Auto Shutter
Day and night switch	IR-CUT infrared filter,supports three modes: infrared, full-color, and intelligent
Noise reduction	Support 2D/3D noise reduction
Wide Dynamic Range	Support digital wide dynamic range
Image flipping	Support horizontal and vertical flipping
Audio Compression	G.711 A-Law, support audio and video synchronization.
Wireless Network	Supports 2.4G & 5.8G dual band+WiFi6 technology, compatible with IEEE802.11b/g/a/n/ac/ax protocol
Infrared distance	Infrared white dual light design, full-color night vision. Illumination distance of 20 meters
Functions	Support two way audio; Regional motion detection, push alarm information; Intelligent humanoid detection;
Storage	Maximum 256GB SD Card (Not include) and cloud storage

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and eficient packagingservices will be provided.

Company Profile

Shenzhen Yichuan Technology Co., Ltd. is mainly engaged in the security camera industry. Having been deeply rooted in this field for years, we boast rich experience. Our main products include WiFi network cameras, 4G cameras, solar-powered cameras, etc. All products undergo strict testing before delivery to ensure quality control. Adhering to the principle of mutual benefit, we provide customers with professional services, high-quality products and competitive prices. Besides, we are committed to developing new products to meet the diverse needs of different customers. We warmly welcome customers from home and abroad to cooperate with us and build a bright future together.

FAQ

1.who are we? We are based in Guangdong, china, start from 2025,sell to Southeast Asia(44.00%),North America(44.00%,DomesticMarket(1 .00%,South Asial(1.00%,Southern Europe(1.00%),Northern Europe(1.00%,Central America(1.00%,WesternEurope(1.00%),Eastern Asia(1.00%),Mid East(1.00%),0ceania(1 .00%),Africa(1.00%),South America(1.00%),EasternEurope(1.00%).There are total about 11-50 people in our office.

2. how can we quarantee quality? Always a pre-production sample before mass production, Always final Inspection before shipment;

3.what can you buy from us? Wifi Wireless Security Camera, 4G Network Cctv Camera, Solar Powered Camera, Etc.

4. why should you buy from us not from other suppliers?

Shenzhen Yichuan Technology Co., Ltd. is mainly engaged in the security camera industry. With years of in-depth cultivation, we have rich experience in this field. Our main products include WiFi network cameras, 4G cameras, solar-powered cameras, etc.
